4-36
SECTION 4
OPERATION
Select MOD METERS Low-Pass Filter Field setting as follows:
OFF
Sets Filter to OFF.
300Hz
Activates 300 Hz High-Pass Filter.
4kHz
Activates 4 kHz Low-Pass Filter.
20kHz
Activates 20 kHz Low-Pass Filter.
EXEC
Executes all edits made to the screen.
Select Speaker/Headphones Filter Field setting as follows:
OFF
Sets Filter to OFF.
C-MSG
Selects C-Message Weighted Filter.
W.B.
Selects no filtering.
AUD-GEN
Routes Audio Signal Internal Modulation sources to
Speaker.
RETURN
Returns to RF Receive Operation Screen.
SETUP MENU
ECTION * * *
LOW
PASS
FILTER
4kHz
OFF
OFF
OFF
SPEAKER / PHONES
* * * PRESS "EXEC" TO ACTIV
W.B.
DEMOD OUT DET OUT
WIDE -
BAND
ON
ON
ON
ON
