Select DEMOD OUT Field setting as follows:
AF CNT
Accesses AF Counter Signal.
DET OUT
Accesses Detector Signal.
C-MSG
Selects Detector Signal through
C-Message Weighted Filter.
DAT DEC
Accesses Data Decoder Signal.
AF DECD
Accesses AF Decoder/SINAD Signal.
MOD MTR
Accesses Modulation Meters Signal.
o Select MOD METERS, DTMT/SINAD, AF CNTR/DECODE, DATA DECODER,
SPEAKER/PHONES or DEMOD OUT Filter settings as desired and execute.
SPEAKER / PHONES
* * * PRESS "EXEC" TO ACTIV
W.B.
DEMOD OUT DET OUT
To Next Page
