IFR COM-120C User Manual

4-55
SECTION 4
OPERATION
PAIR
Pairs Generate and Receive RF operation.
UNPAIR
Unpairs Generate and Receive RF.operation.
o Set Frequency Offset to desired value.
Range is from -999.750 to 999.750 MHz.
O
T
e
n
To activate/ deactivate Pair/ Unpair Function, press F5.
Set Level as follows:
dBm
Selects dBm as Output Level Units.
uV
Selects µV as Output Level Units.
mV
Selects mV as Output Level Units.
V
Selects V as Output Level Units.
Select Output as follows:
T/R
Selects T/R Connector as output
connector.
AUX
Selects AUX RF Connector as output
connector.
T/R Gate
Selects T/R Connector as gated output
connector.
AUX Gate
Selects AUX RF Connector as gated
output connector.
RF: 10.0000 MHz P
- 40.0 dBm
T/R
Level :
Output :
- 40.0 dBm
T/R
Level :
Output :
