6-90
SECTION 6
OPTIONS
10. Deviation: (Receive)
This field shows the Repeater’s Transmit Deviation for Voice or Data in kHz. A ‘V’
symbol means Voice Deviation. A ‘D’ symbol means Data Deviation (low-
frequency data). Value range: 0.00 to 100.0 kHz.
11. AF Frequency:
This field shows the Repeater’s Transmitter Audio Frequency in Hz. It is a
display-only field (meter) with no cursor position. Measuring range: 300 to
4500 Hz.
12. Distortion: (Receive)
This field shows the Repeater’s Transmitter Distortion in %. Value range: 0.0 to
20.0%. Also used to show decoded DTMF digits by pressing the DTMF softkey.
13. Extended
Meas:
This field allows access to one of three external screens: Scope, Analyzer or
Digital Voltmeter (DVM). If a Group Call (PTT) was made to another Radio and is
still in progress, it is possible to access any of the three screens without
interrupting the call. The
only
way to enter the extended screens is to use the
softkeys. The ‘Return’ field in the extended screen allows a return to the
Repeater Simulator.
14. RF: (Generate)
This field shows the current RF Frequency of the EDACS Control Channel for the
Generator side of the Radio Simulator. This field is editable (which puts the
Control Channel in ‘Manual’ mode). Value range: 0 to 1000.0000 MHz.
15. Level:
This field is used to set the Generator’s RF Output Level in dBm. Value range:
-40 to -130.0 dBm (T/R), 13.0 to -130.0 dBm (AUX) with AUX option.
16. Output:
This field is used to set the Generator’s RF Output source to the T/R port or the
Auxiliary (AUX) RF port. Valid values: T/R or AUX.
