1-12
SECTION 1
INTRODUCTION
MODULATION
Frequency Modulation
RF Frequency Range:
Deviation Range:
Deviation Resolution:
Rate:
Accuracy:
Distortion:
EXT MOD Sensitivity:
250 Hz to 1 GHz
100 Hz to 100 kHz
10 Hz (0.01 to 2.55 kHz)
50 Hz (2.60 to 12.75 kHz)
100 Hz (12.8 to 25.5 kHz)
500 Hz (26.0 to 100.0 kHz)
10 Hz to 20 kHz (FSK rates up to 40 kbps
± 5% + Residual FM + Resolution (1 kHz
rate, GEN1, GEN 2, EXT MOD)
± 10% + Residual FM + Resolution (DATA
GEN)
± 15% + Residual FM + Resolution (DTMF
GEN)
<2% (1 kHz sine wave, 10 kHz deviation,
0.3 to 3 kHz BW)
2 kHz/Vpk ± 15% (FM Narrow)
Amplitude Modulation
RF Frequency Range:
AM Depth Range:
Resolution:
Rate:
Accuracy:
Distortion:
EXT MOD Sensitivity:
250 kHz to 1 GHz
30% to 90%
0.5%
100 Hz to 10 kHz
± 5% + Residual AM + Resolution (1 kHz
rate, RF Level <0 dBm)
± 15% + Residual AM + Resolution (RF
Level <0 dBm)
<2% (30% to 90% modulation, 1 kHz
rate, 0.3 to 3 kHz BW)
5% to 15% per Vpk
