1-13
INTRODUCTION
Phase Modulation
RF Frequency Range:
Modulation Range:
Resolution:
Rate:
Accuracy:
EXT MOD Sensitivity:
250 kHz to 1 GHz
0.1 to 10 rad peak
0.01 rad (<2.55 rad)
100 Hz to 6 kHz
± 5% + Residual PM + Resolution (1 kHz
rate)
± 15% + Residual PM + Resolution (DTMF
GEN)
2 rad/Vpk, ± 15%
AUDIO/DATA GENERATORS
AF GENERATOR
Frequency Range:
Frequency Resolution:
Frequency Accuracy:
Output Range:
High Level:
Low Level:
Output Resolution:
High Level:
Low Level:
Output Accuracy:
High Level:
Low Level:
THD:
Wave Shapes:
5 Hz to 20 kHz (sinewave only)
5 Hz to 10 kHz (other wave shapes)
0.1 Hz
Same as Master Oscillator,
±
0.1 Hz
0.01 to 2.5 Vpk (into 150 Ω )
1 to 250 mVpk (into 150 Ω )
0.01 Vpk
0.1 mV
± 3% full range ± 5 mVpk (≤10 kHz,
≥ 0.03 Vpk)
± 7% full range ± 5 mVpk (>10 kHz,
≥ 0.03 Vpk)
± 4% full range ± 0.25 mVpk (≤10 kHz,
0.03 Vpk) < level, ≥1 mVpk)
± 7% full range ± 0.25 mVpk (>10 kHz,
0.03 Vpk < level, ≥1 mVpk)
<0.7% (1 kHz sinewave, 2.5 Vpk, 150 Ω
Load)
<1% sinewave (all other frequencies/
levels)
Sine, Ramp, Square, Triangl
