D-3
FUNCTION DESCRIPTION
ANALY Displays abbreviated Analyzer.
ANT Selects ANTENNA Connector as RF input connector.
APP Displays when there are stored macro files. A loaded macro application appears as
Item Number 4 on the List Setup Screen.
ARCHIVE Sets or clears Archive attribute to a file to indicate the file has been changed.
AUD/DAT Selects AUDIO/DATA IN Connector as input source for meter.
Aud-Gen Routes Audio signal from internal Audio/Data/Signaling Generators, as composite
signal, to Speaker and PHONES Connector.
AUTO Selects
Autorange as
active upper
range for SINAD
and Modulation
Meters.
Automatically
adjusts to a
higher or lower
range if signal
increases or
decreases to a
specified level
of the current
setting.
Selects Auto as
Trigger type for
Oscilloscope.
Allows Decode
Function to
determine
Message Type
from received
data.
Automatically
decodes 1200 or
2400 baud rate
incoming
POCSAG data.
Accesses
Automatic Test
screen.
AUX Selects AUX RF OUT as output connector. Indicator lights up.
AUX Gate Selects AUX RF OUT as output connector. Indicator lights up. Only active when
microphone is keyed.
AVG Activates/deactivates Average Oscilloscope Operation Mode.
BER Accesses Bit Error Rate Option.
BER + Inserts Bit Errors in the control channel signaling. This function increases the number
of bit errors in an erred frame.
BER INT Inserts Bit Errors in the control channel signaling. This function decreases the
interval at which erred frames are inserted in the control channel.
BIDIR Sets Bidirectional Print Mode.
BMPMakes the file type a Bitmap format. There is a COLORS field with this selection.
(see, NORMAL and INVERT)
BOTH Selects + and – peak deviation. The upper limit applies to the largest peak Positive
reading and the lower limit applies to the largest Negative reading. For Peak hold
readings, Peak Hi applies to the largest Positive peak reading found and Peak Lo
applies to the largest Negative reading found.
BURST Activates single transmission of selected signal.
BUSY Sets Status to BUSY (Busy Home Repeater).
