D-8
FUNCTION DESCRIPTION
LOCK Sets frequency used for Generate, Receive
and Spectrum Analyzer operation to same
frequency as current RF Field. Change
displays in all three operation screens
when engaged.
Locks the Tracking Generator center
frequency at a constant offset from the
analyzer center frequency. Changing the
analyzer center frequency changes the
Tracking Generator center frequency by a
like amount.
LOOP Selects Loop Run Mode in optional BER Meter operation.
LTR Accesses LTR Trunking Option.
MANUAL Accesses Manual Test screen.
MAX Displays Maximum Limit values only.
MEAS-HI Accesses the Parametric Measurements screen for the High Channel Handoff.
MEAS-LO Accesses the Parametric Measurements screen for the Low Channel Handoff.
MENU Displays pop up menu with multiple selections.
MIC Accesses MIC Modulation parameters.
MIN Displays Minimum Limit values only.
MIN HOLD Activates/deactivates Minimum Hold Oscilloscope Operation Mode.
MOBILE Initiates Manual Mobile Initiated Call Test.
MOD MTR Routes Modulation Meter signal to DEMOD Connector.
MONITOR Accesses Off-Air Monitor screen.
MOVE Moves a file from one directory to another.
Enter a drive, directory and name to
relocate the file. Move the file within the
same drive or from one drive to another.
Moves the control channel to that
displayed in the CCH# field and sets the
RF frequencies accordingly.
MPT1327 Accesses MPT1327 Trunking Option.
mV Sets Output level Units to mV.
NAR 1 Selects Deviation Range, 12.75 to 25 kHz.
NAR 2 Selects Deviation Range, 2 to 12.75 kHz.
NAR 3 Selects Deviation Range, <2 kHz.
NARROW Sets System Band to Narrow (900 MHz).
NETWORK Accesses SETUP Network Definition screen.
NO ACKS When selected, all acknowledgement messages are filtered. Use in conjunction with
NO ALH if required. (see, NO ALH)
NO ALH When selected, filter out ALHOA and BCAST messages.
NORM Selects Normalized Trigger type. Selects Normal for +/- peak div by 2.
NORMAL The printed screen
orientation is black
background with white text.
(see, BMP and PCX)
Selects Normal Data
Polarity in optional BER
Meter operation.
Sets Decode/Encode Data
to normal.
