1-22
SECTION 1
INTRODUCTION
Level
Display:
Vertical Resolution:
Range (Dynamic):
Bandwidth Switching Error:
Log Linearity:
Input Attenuator:
Log, 2 and 10 dB/div
1 dB
60 dB
<3 dB
± 2 dB (referenced to -40 dBm, 15° to
35° C)
± 3 dB (referenced to -40 dBm, 0° to 15° C
and 35° to 50° C)
0, 30 dB (ANT Connector)
INPUT/OUTPUT CONNECTORS
RS-232 Connector
Operations Mode:
Baud Rates:
Stop Bits:
Parity:
Handshake:
Off, PC (Input/Output)
100, 150, 300, 600, 1200, 2400, 4800,
9600, 19200, 38400
1, 2
Odd, Even, None
None, Xon/Xoff, CTS/RTS
MASTER OSCILLATOR
TCXO
Frequency:
Uncertainty:
Temperature Stability:
Aging Rate:
10 MHz
±0.1 ppm
±0.2 ppm (0° to 50° C)
±0.5 ppm/year
POWER REQUIREMENTS
Line Voltage:
DC Input:
Power Consumption
AC:
DC:
100 to 120 VAC at 60 Hz
220 to 240 VAC at 50 Hz
12 Vdc, 24-30 Vdc
110 VAC, 150 W maximum, 110 W typical
230 VAC, 150 W maximum, 95 W typical
150 W maximum, 90 W typical
