1-23
INTRODUCTION
FUSE REQUIREMENTS
AC Fuses:
100 to 120 VAC:
220 to 240 VAC:
DC Fuse:
Battery Fuse:
3.0 A, 250 V, Type F (5 x 20 mm)
3.0 A, 250 V, Type F (5 x 20 mm)
10 A, 32 V, Type F (AGC)
10 A, 32 V, Type F (AGC)
SAFETY CONDITIONS
Use:
Altitude:
Operating Temperatures:
Relative Humidity:
Mains Supply Voltage Fluctuations:
Transient Overvoltages:
Pollution Degree:
Non-condutive pollution only
≤ 4000 meters (13,124 feet)
0° to 50° C
≤ 80% for temperatures up to 31° C
decreasing linearly to 50% at 40° C
≤±10% of the nominal voltage
According to Installation Category II
2
GENERAL CHARACTERISTICS
Dimensions:
Weight:
40.0 cm (15.75”) wide, 19.0 cm (7.5”)
high, 42.9 cm (16.875”) deep (without
bail handle and front panel cover)
44.0 cm (17.32”) wide, 19.0 cm (7.5”)
high, 53.7 cm (21.125”) deep (with bail
handle and front panel cover)
17.3 kg (38.5 lbs.) (without options, lid,
accessories)
