SECTION 3
COMPOSITE
14. Power/Received Level Meter
Power Meter displays power level of signal received through T/R Connector only
in dB and Watts. RECEIVED LEVEL Meter displays referenced Power Level of
signal received through ANTENNA Connector only in dBm and µV.
15. RF Error Meter
Displays difference in RF Field (2) and frequency of received signal.
16. AF Frequency Counter
Displays Audio Frequency of received signal.
17. Scan Width
Displays current Scan Width. This field is editable.
18. Scope/Analyzer Screen
Displays digitized trace of specified signal as Oscilloscope or Spectrum Analyzer.
19. Scope/Analyzer Prompt
Displays current operation function. Used to toggle between two functions.
