4-3
SECTION 4
OPERATION
o Set Output Level Units as follows:
dBm
Selects dBm as Output Level Units.
uV
Selects µV as Output Level Units.
mV
Selects mV as Output Level Units.
V
Selects V as Output Level Units.
SINAD=
Accesses SINAD Search Function.
S=On/Off
Activates/deactivates SINAD Search
Function.
To operate with SINAD Search Function:
SINAD=
Accesses field to set SINAD Search
Function value. Range of SINAD= is 6 to
55 dB.
S=On/Off
S=
is displayed beside Output Level
Field to activate SINAD Search Function.
Press F6 again to deactivate.
RF: 10.0000 MHz
FL: OFF
Level: -30.0 dBm
Output: T/R
SINAD = 15.0 dB
Level: -20.0 dBm S=
