Table 49: Optical interface Support and Copper Interface Support for 1-gigabit SFP Transceivers

in EX4550 Switches (continued)

ValueSpecificationEthernet Standard

EX-SFP-GE10KT13R14Model number1000BASE-BX-U

1000 MbpsRate

LCConnector type

SingleFiber count

1310 nmTransmitter wavelength

1490 nmReceiver wavelength

–9 dBmMinimum launch power

–3 dBmMaximum launch power

–30 dBmMinimum receiver sensitivity

–3 dBmMaximum input power

SMFFiber type

9/125 µmCore/Cladding size

–Modal bandwidth

10 km (6.2 miles)Distance

AvailableDOM support

•

EX4550-32T-AFI, EX4550-32T-AFO, EX4550-32T-DC-AFI,

EX4550-32T-DC-AFO, EX4550-32F-AFI, EX4550-32F-AFO,

EX4550-32F-DC-AFI, and EX4550-32F-DC-AFO

switches—Junos OS for EX Series switches, Release 12.2 or

later

•

EX4550-32F-S switches—Junos OS for EX Series switches,

Release 12.3R5 or later

Software required
