Section 3: Functions and features Series 2280 Precision DC Power Supply Reference Manual
3-14 077085503 / March 2019
To use the front panel to view the contents of the reading buffer:
1. Press the MENU key.
2. Under Views, select Sheet.
3. Select the button next to Data Sheet. The data is displayed.
4. If you want to view the statistics, select the button next to Statistics. The Statistics screen is
displayed.
5. Press the button next to On. The statistics results are displayed below the data table. To
configure the statistics function, see Configuring the statistics applied to data in the buffer (on
page 3-15).
Figure 60: Data sheet in power supply function
6. Press the HOME key to return to the home screen.
Go to home screen 3. Press the Data Sheet soft key to view the buffer.
