Keithley 2280 Series Reference Manual

Series 2280 Precision DC Power Supply Reference Manual Section 3: Functions and features
077085503 / March 2019 3-15
Using the front panel to save buffer content to files
To use the front panel to save or append buffer content to files:
1. Insert a USB flash drive into the USB port.
2. Press the MENU key.
3. Under Measure, select Data Buffers.
4. Select the Export To USB button. A keyboard is displayed.
5. Enter the name of the file in which to save the readings.
You only have to enter the name of the file you want to save. It is not necessary to enter the file
extension. All files are saved as .csv files.
6. Select Yes to confirm saving the file. When the DATA BUFFERS window is displayed again, the
file is saved.
7. Press the HOME key to return to the home screen.
Configuring the statistics applied to data in the buffer
The data buffer provides the following statistics:
Average
Minimum
Maximum
Peak-to-peak
Standard deviation.
Specifying the statistics applied to the data in the buffer
Using the front panel:
1. Press the MENU key.
2. Under Measure, select Data Buffers.
3. Select the Statistics button. The Statistics window is displayed.
4. Enable the statistics you want to calculate.
