Section 2: General operation Series 2280 Precision DC Power Supply Reference Manual
2-22 077085503 / March 2019
Trigger Digital In/Out menu
This menu allows you to configure the mode for each digital I/O line. The Series 2280 has 6 digital I/O
lines (line 1 to line 6). For details, refer to Digital I/O (on page 3-19).
Setting
Description
Line 1
Specify one of the following line modes for digital I/O line 1:
 Trigger In
 Output HI
 Output LO
 Manual In
Line 2
Specify one of the following line modes for digital I/O line 2:
 Meter Out
 Output HI
 Output LO
 Manual In
Line 3
Specify one of the following line modes for digital I/O line 3:
 Fault Out
 Output HI
 Output LO
 Manual In
Line 4
Specify one of the following line modes for digital I/O line 4 to line 6:
 Output HI
 Output LO
 Manual In
Line 5
Line 6
