Control the instrument through the virtual front-panel web page
You can operate the instrument using the virtual front panel shown in the figure below.
Figure 43: Series 2280 LXI virtual front panel
For more information about using the virtual front panel, refer to Front-panel user interface (on page
2-4).
The Series 2280 only allows fewer than three clients to open the virtual front panel web page at the
same time. Only the first successfully connected client can operate the instrument. Other clients can
only view the virtual front panel.
Send SCPI commands through the web interface
You can send SCPI commands from the web interface.
To send SCPI commands using the web page:
1. From the navigation bar on the left, select SCPI command. The web page is displayed as
follows.
