Keysight E4980A/AL Precision LCR Meter 63
Display Format
MEAS DISPLAY Page
3-
Step 4. Use the softkeys or numeric entry keys to enter the test signal level. When
data is entered with the numeric entry keys, the softkeys change to units
labels (mV, V, uA, mA, A).
Softkey Function
INCR ++ Increases the oscillator’s output level with a resolution shown in
Table 3-14 or Table 3-15.
INCR + Increases the oscillator’s output level with a resolution shown in
Table 3-10 to Table 3-13.
DECR - Decreases the oscillator’s output level with a resolution shown in
Table 3-10 to Table 3-13.
DECR -- Decreases the oscillator’s output level with a resolution shown in
Table 3-14 or Table 3-15.
Table 3-14 Oscillator’s voltage level that can be set with INCR ++ / DECR --
INCR ++ / DECR -- (Vrms)
0,
1 m, 2 m, 3 m, •••, 9 m
10 m, 20 m, 30 m, •••, 90 m
100 m, 200 m, 300 m, •••, 900 m
1, 2, 3, •••, 9
1
1. The voltage level can be set to more than 2 V only when option 001
is installed.
10, 20
1
Table 3-15 Oscillator’s current level that can be set with INCR ++ / DECR --
INCR ++ / DECR -- (Arms)
0,
10 , 20 , 30 , •••, 90 
100 , 200 , 300 , •••, 900 
1 m, 2 m, 3 m, •••, 9 m
10 m, 20 m, 30 m, •••, 90 m
1
1. The current level can be set to more than 20 m only when option
001 is installed.
100 m
1
