8.5 Hydraulic connection to block the coaster/steering axle (special equipment)
Connect the separate hydraulic hose from the locking cylinder of the steering axle (red 7) onto
the single-acting control unit on the tractor.
Note
Observe the user instructions of the tractor manufacturer on parallel operation of the tractor
control devices! The locking cylinder of the steering axle must be connected before or at the
same time as the other hydraulic supply elements of the machine!
