Driving and Transport
173
Pos: 30.53 /Übersc hriften/Überschri ften 3/U-Z/Unterlegkei le @ 33\mod_1254202555 660_78.docx @ 318451 @ 3 @ 1
9.4.2 Wheel chocks
Pos: 30.54 /BA/Fahren und Transport/Großpacken presse/Unterlegk eile Bild BP 12130 HS Baur eihe @ 71\mod_1305802630 563_78.docx @ 640755 @ 1 @ 1
1
BPHS0054
Fig. 111
Pos: 30.55 /BA/Fahren und Transport/Großpacken presse/Unterlegk eile Text BP HS Baureihe @ 71\ mod_1305799627493_7 8.docx @ 640727 @ 3 @ 1
The wheel chocks (1) are located at the rear on the right and left next to the bale channel
chamber
• Always place the wheel chocks (1) in front of and behind the wheels (this will prevent the
machine from rolling away).
Note
If the machine has a guided coast-down tandem axle (optional), it must be secured with wheel
chocks on the front axle to prevent it from rolling away.
