Krone Big Pack 4x4 - Filling Quantities and Lubrication Designations for Gearboxes

Maintenance
258
Pos: 36.47.1 /Überschr iften/Überschr iften 2/F-J/Füllmeng en und Schmiermittelb ezeichnungen der Getri ebe @ 0\mod_119695109404 6_78.docx @ 15335 @ 3 @ 1
12.16 Filling Quantities and Lubrication Designations for Gearboxes
Pos: 36.47.2 /BA/E inleitung/Technisc he Daten/Grosspackenpr esse/BiG PACK 890_12 70_1290 HS_1290 HDP HSTechnisc he Daten: Betriebss toffe Getriebe BP 4x4 ( 2013-06-24 11:20:28) @ 70\ mod_1305724769170_78. docx @ 639597 @ @ 1
Amount
[litres]
Designation/brand
Bio-degradable
lubricants
Main gearbox 35
SAE 90 GL 4 or
Esso-Spartan EP 150
Shell Omala Oil 150
Fuchs- EP 85 W90
Castrol EPX 90
On request
Packer gearbox 4
Knotter/packer transfer gearbox 1
Pick-up gearbox, upper 1.6
Pick-up gearbox, lower 1.6
Cutting system gearbox for XC,
upper
2.8
Cutting system gearbox for XC,
lower
1.75
Pos: 36.47.3 /Überschr iften/Überschr iften 3/F-J/Füllmeng e und Ölbezeichnung der Bor dhydraulik @ 17\mod_12361 77374918_78.doc x @ 201862 @ 3 @ 1
12.16.1 Oil quantities and designations for the on-board hydraulic system
Pos: 36.47.4 /BA/W artung/Großpackenpres sen/Technische Daten: Füllmenge und Ölbezeic hnung der Bordhydr aulik @ 17\mod_1236178420965_78. docx @ 201932 @ @ 1
Quantity
ltr.
Designation/brand
Bio-degradable
lubricants
Oil container on baler 15
Fuchs Renolin MR 46 MC
BP Energol SHF 46
Shell Tellus 46
Esso Univis N 46
Aral Vitan VS 46
on request
Pos: 36.47.5 /Überschr iften/Überschr iften 3/F-J/Füllmeng e und Ölbezeichnung des Kom pressors @ 17\mod_12361774 27355_78.docx @ 20188 7 @ @ 1
12.16.2 Oil quantities and designations for the compressor
Pos: 36.47.6 /BA/W artung/Großpackenpres sen/Technische Daten: Füllmenge und Ölbezeic hnung des Kompressors @ 17\ mod_1236178607105_78. docx @ 201957 @ 2 @ 1
Quantity ltr. Designation/brand
Bio-degradable
lubricants
Up to the top
dipstick marking
(0.2)
Standard engine oil
SAE 20 or 20 W 40
on request
Pos: 36.47.7 /BA/W artung/Zeitinter valle an den Getrieben 200 h @ 0\mod_ 1196951919921_78.doc x @ 15373 @ 2 @ 1
12.16.3 Oil Level Check and Oil Change Intervals (Gearboxes)
Note - Oil level check and oil change (gearboxes) and lubricating the machine
Effect: Long expected service life of machine
• First oil change on all gearboxes after 50 operating hours, then every 200 operating
hours (but at least once a year).
• Before using the machine always check the oil level.
• With bio-degradable oils the changing intervals must be complied with absolutely
because of ageing of the oils.
Pos: 36.47.8 /BA/W artung/Ölkontrolle_W echsel/Großpacken pressewaagerechte St ellung (2013-06-05 14:4 0:14) @ 24\mod_12415966 84018_78.docx @ 246596 @ @ 1
Note
Make sure that the baler is in horizontal position during the oil level check. Use the lower edges
of the twine boxes as a reference surface.
