Krone Big Pack 4x4 - Cutting length

Operation
176
Pos: 32.6.5 /BA/Ei nstellungen/Schnei dwerkSchnittlänge BigP ack (2013-10-18 09: 20:26) @ 32\mod_1253695637 412_78.docx @ 316314 @ 3 @ 1
10.2.2 Cutting length
The cutting system of the Big Pack 890 XC can be fitted with a maximum of 16 blades. The
cutting system of the Big Pack 1270 XC / 1290 XC / 1290 HDP XC / 12130 XC / 4x4 can be
fitted with a maximum of 26 blades.
The blades are separated in two groups (upper blade control system and lower blade control
system).
The theoretical chop length is, with full equipping, 44 mm. The chop length is determined by the
number of blades used and the position of the blade control system.
The following blades can be optionally operated via the upper and lower blade control system
with full equipping on
Big Pack 890 XC 0, 8, 8 or 16 blades.
Big Pack 1270 XC / 1290 XC / 12130 XC / 4x4 0, 13, 13 or 26 blades.
Pos: 32.6.6 /BA/E instellungen/Schnei dwerkSchnittlänge Tabelle durch Messerbes tückung BigPack HS Baureihe ( 2013-10-18 09:32:22) @ 62\mod_1299594560312_ 78.docx @ 573378 @ 23 @ 1
Table cutting length depending on blade equipping
Cutting length
mm
Number of blades
Deployed blade compartment
BP 890 BP1270 / BP1290
/ BP 4x4
- 0 0 random
44 16 26 each
88 8 13 every 2nd
176 4 6 every 3rd
Pos: 32.6.7 /BA/E instellungen/Schnei dwerkSchnittlänge Tabelle Messerschalt ung BigPack (2013-10-18 0 9:28:34) @ 32\mod_1253697 890568_78.docx @ 316569 @ @ 1
Table cutting length depending on blade control system (with full equipping)
Cutting length mm
Number of blades
Upper blade
control system
Lower blade control
system
BP 890 BP1270 / BP1290 /
BP 12130 / BP 4x4
- 0 0 Off Off
88 8 13 On Off
88 8 13 Off On
44 16 26 On On
