3.8 General Technical Description
PTO speed 1000 rpm
Cardan shaft Tractor side: Wide angle
Towing ring ball head coupling
- perm. supporting load: up to 2000 kg
Bottom attachment with ball head coupling
- perm. supporting load: up to 2500 kg
Caution! When an adjustment is made, the hexagon
head screws must be tightened to a torque
indicated in the “Tightening torques” table in
the chapter “Maintenance”.
Support Parking jack, retractable - manually adjustable in height.
Optional: Hydraulic parking jack
Uncontrolled 'EasyFlow' pick-
up drum
Hydraulic lift
Height adjustment by perforated bar on the supporting wheel.
Tine mounting: 5 pieces
Number of tines: 20 double tines / tine mountings
Lateral feed Right and left auger conveyor
Variable Feed System (VFS) Forced intake by feed packer drum
Feed packer drum with: 4 feed packers and 1
switchable feeder packer
The XC version includes a cutting system placed in front.
Baling ram
Length of stroke 800 mm
38 strokes per minute
The baling ram moves on 4 rollers (7 blades on plunger).
Setting the baling density Electro-hydraulic power regulation (each adjustable from the
tractor)
Twine box on both sides, for altogether 32 balls of twine
Twine Synthetic twine (100-130 m/kg)
For balls of twine end and torn
twine
Electrical twine control with acoustic and optical signal.
Bale ejector/bale unloading One-part bale chute (must be hinged up in transport).
Operation according to version (Medium - Comfort) at the
machine or from the tractor
Parking brake Operation by hand crank at the rear left of the baler
Pos: 11.23 /BA/Einste llungen/Großpackenpr esse/Bindegarn ei nfädeln/Hinweis Ver wenden Sie nur KRONE Origi nal Bindegarn @ 32\mod_12530839 55561_78.docx @ 308448 @ @ 1
Note
Only use original KRONE twine
