KRONE ISOBUS-Terminal CCI 100
86
Pos: 22.65 /BA/Inf o-Center/CCI-I SOBUS-Terminal/CCI-Bi G Pack/Hauptmenüs/ Hauptmenü 1 Einstellungen/ Menü 1-1-1 „Korr ekturwert Ballenlänge“ HS Baureihe @ 99\mod_132999407 3656_78.docx @ 886978 @ 3 @ 1
6.10.2 Menu 1-1-1 „Correction Value for Bale Length“
CC0000100
Fig. 52
Because of different properties of materials (for example straw or silage), the actual bale length
can differ from the pre-set setpoint. The correction value can be used to correct this deviation.
Factory setting: 100%
Calling the Menu
The main menu 1-1 “Knotter Setting” is called.
• Select menu 1-1-1
by pressing function key or , the symbol is highlighted in
grey
• Press function key
The display shows menu 1-1-1 “Correction Value Bale Length”.
The bar display and the percentage value show the set correction value. The symbol
in the
upper line indicates that the displayed value is saved.
Setting and Saving the Correction Value
If the bale is too long, reduce the correction value. If the bale is too short, increase the
correction value.
• Set the desired correction value with the function key
or . The symbol in the top
line goes out
• Press the function key
. The set correction value is saved and the symbol
appears in the upper line
• By pressing the function key
, the value of the factory setting is displayed (press
function key
, the value of the factory setting is saved, the symbol in the upper
line appears)
• Pressing the function key
closes the called up menu
• Pressing the function key
and holding it down brings up the basic screen
