10.2 Cutting system
Pos: 32.6.2 /BA/S icherheit/Schnei dwerk/Gefahr- Wartungs- , Montage-, Reparatur - und Einstellarbeit en Schneidwerk @ 20\mod_12 38592519291_78.doc x @ 223461 @ @ 1
DANGER! - Maintenance, assembly, repair and adjustment work
Effect: Danger to life, injuries or damage to the machine.
The following general rules apply to all maintenance, assembly, repair and adjustment work:
• Bring the machine to a complete stop.
• Switch off the P.T.O. shaft. Switch off the engine and remove the ignition key. Apply the
flywheel brake
• Secure the tractor and machine against rolling
• Secure the Pick-up against unintentional lowering by moving the shut-off valve on the left
side of the machine
• Risk of injury when attaching or removing the cutters. The blades should only be touched
with suitable gloves
Pos: 32.6.3 /BA/E instellungen/Schnei dwerk/Allgemeines Sc hneidwerk BigPack ohne B lindmesser @ 91\mod_13 26705764014_78.doc x @ 780502 @ @ 1
10.2.1 General
The Big Pack XC has a cutting system with a cutting cylinder and fixed blades. Cutting allows
for improved further processing of the big pack and makes it possible to increase the density of
baled material. The blades can be swivelled out of the conveyor channel from the tractor
hydraulically if there are blockages. Each blade is separately protected against overload. The
machine can also be used without blades. The cutting cylinder then takes over the function of a
conveyor between the pick-up and the pre-baling channel.
