Commissioning
51
If the adjustment of the towing ring is not adequate, adjust the side parts (4).
To do this:
• Unscrew the screws (3)
• Adjust the height of the front parts of the drawbar (4) to the height of the tractor hitch
• Fit and tighten the screws (3)
Changing the drawbar hitch
The drawbar is set as standard as the bottom hitch (a). To set as top attachment (b), rotate both
front parts of the drawbar (4) by 180 degrees.
To do this:
• Unscrew the screws (3)
• Remove the front parts of the drawbar (4) and rotate by 180 degrees
• Using the screws (3), attach the turned front parts of the drawbar between the drawbar
(5) and tighten the screws
Pos: 18.7 /BA/War tung/Hinweis Anzugsmomen te beachten (siehe Kapite l Wartung „Drehmomente“ ). @ 26\mod_124573625929 9_78.docx @ 263361 @ 2 @ 1
Note
Mind the tightening torques (refer to chapter Maintenance “Tightening torques”).
