3.2 ready2_educate_basic
Description
The ready2_educate_basic cell is used for teaching operator control and
basic programming of KUKA robots. It contains ten cubes that can be
used for programming simple pick-and-place tasks.
Overview
Fig. 3-1: Overview, ready2_educate_basic
1 KR 3 R540 robot
2 Mounting plate for control elements
3 2-jaw parallel gripper
4 Application plate
5 Cell housing
3.2.1 KR C4 compact robot controller
Description
The KR C4 compact robot controller is used for the robot.
Further information is contained in the operating instructions for the ro-
bot controller.
