Overview
Fig. 3-36: ready2_educate_advanced_vision
1 KR 3 R540 robot
2 Mounting plate for control elements
3 Vision
4 2-jaw parallel gripper
5 Application plate with components
6 Cell housing
3.6.1 KR C4 compact robot controller
Description
The KR C4 compact robot controller is used for the robot.
Further information is contained in the operating instructions for the ro-
bot controller.
Fig. 3-37: KR C4 compact
ready2_educate
