Kuka ready2 educate - Control Panel; Operator Control and Display Elements

Fig. 3-27: KR C4 compact
3.5.2 Control panel
Description
The control panel contains the display and operator control elements, the
EMERGENCY STOP device and the “Ackn.” button for operator safety.
Fig. 3-28: Control panel
1 smartPAD 2 Operator control and display
elements
3.5.2.1 Operator control and display elements
Fig. 3-29: Operator control and display elements
ready2_educate
30/154 | www.kuka.com BA ready2_educate V8 | Issued: 05.09.2018
Product description
