Item
Description
Pressing the EMERGENCY STOP device stops all motions.
Before operation can be resumed, the key in the
EMERGENCY STOP device must be turned to release it.
4 Acknowledge operator safety
5 USB connection
6 KSI connection
7 Profinet connection
8 Blanking cover
3.6.3 Gripper system
Description
The 2-jaw parallel gripper is used for gripping, positioning and setting
down parts.
Fig. 3-40: 2-jaw parallel gripper
1 Energy supply system
2 Gripper holder
3 2-jaw parallel gripper
3.6.4 Application components
Description
The gripper is used to grip the various components and set them down in
new positions.
