4.7 Plates and labels
The following plates and labels are attached to the ready2_educate cell.
They must not be removed or rendered illegible. Illegible plates and labels
must be replaced.
Bulkhead-mounted housing
Fig. 4-25: Plates and labels
Item
Description
1
Description of fuses on the inside of the maintenance door for
ready2_educate_basic and ready2_educate_pro.
ready2_educate
72/154 | www.kuka.com BA ready2_educate V8 | Issued: 05.09.2018
Technical data
