14.5.5 Exchanging the blade-type fuse
Precondition
• The robot controller is switched off and secured to prevent unauthor-
ized persons from switching it on again.
Procedure
1. Open the maintenance door.
2. Remove the blade-type fuse from the electrical system mounting plate.
3. Insert a new blade-type fuse.
Fig. 14-19: Exchanging the blade-type fuse
1 Blade-type fuse
14.5.6 Exchanging the gripper cable
Precondition
• The robot controller is switched off and secured to prevent unauthor-
ized persons from switching it on again.
Procedure
1. Detach the plug connection at the rear of the gripper.
Fig. 14-20: Detaching the plug connection
1 Plug connection
ready2_educate
132/154 | www.kuka.com BA ready2_educate V8 | Issued: 05.09.2018
Repair
