The MASTER Page
9-7
The MASTER Page
NOTE:InSetupmodeandSongmode,thispagecorrespondsinappearanceandfunctiontothe
MASTFXpage,thoughtheMASTFXpageworksonapersetup/songbasis.
PressingtheMASTERsoftbuttoncallsuptheMASTERpage.TheMASTERpagecontainsthe
settingsforthemasterEQandCompressor.The
pageappearsasshownbelow:
ThetwoboxesinthechainontheMASTER page arethemasterCompressorandEQEffects.
PresstheEditbuttonwhileeitheroftheseboxesisselectedtoedittheparametersforthebox’s
effect.SeeEqualizers(EQ) on page 9‐13andCompressors,Expanders,andGates on page 9‐
14for
descriptionontheEQandCompressorparameters.
Mode
ThesettingfortheMasterEffectscanbesetdirectlyonthispage,oroptionallyinthecontrol
setup.TosetuptheMasterEffectsfromtheMASTERpage,settheModeparametertoMaster.
Tousethesettingsinthecurrentcontrolsetup,selectSetup.ControllingtheMasterEffects
from
thecontrolsetupallowsforconvenientswitchingbetweendifferentconfigurations.
Order
UsetheOrderparametertodeterminetheorderofthetwoeffects.SettingOrdertoCompressor
=>EQroutessignalthroughtheCompressorfirst,andthenthroughtheEQ.SettingOrdertoEQ
=>CompressorroutessignalthroughtheEQfirst,andthenthroughtheCompressor.
Master FX
TheMasterFXparameterdetermineswhethertheMasterEffectsareenabledorbypassed.
SettingMasterFXtoMasterFXEnabledenablestheMasterEffects.SettingMasterFXtoMaster
FXBypassedbypassestheMasterEffects,andeffectivelyremovesthemfromthesignalpath.
SeeMasterEffects on page 9‐4foradescriptionof
theMasterEffects.
Parameter Range of Values Default
Mode Master, Setup Master
Order Compressor => EQ,
EQ => Compressor
Compressor => EQ
Master FX Master FX Enabled,
Master FX Bypassed
Master FX Enabled
