Program Mode
The DSP Control (DSPCTL) Page
The DSP Control (DSPCTL) Page
Beforereadingfurther,besuretoreadAlgorithmBasics on page 6‐13andCommonDSPControl
Parameters on page 6‐14.
PresstheDSPCTLsoftbuttontocalluptheDSPControl(DSPCTL)page,whichisdisplayed
below:
Eachfieldintheleft‐handcolumnofthepageisafunction‐parameterofthecurrentlayer’s
algorithm.Youcancoarselyadjustthefunction‐parameterintheseleft‐handfields—asnotedin
CommonDSPControlParameters,anyadjustmentsmadetothefunction‐parametersonthe
DSPCTLpagearereflectedinthecorrespondingfunction‐parametersontheDSPMODpage.
Theright‐handsideoftheDSPCTLpageis
thesubpageofthehighlightedfunction‐parameter—
onthesubpagearethefineadjustparametersandhard‐wiredparameters.Toaccessthe
parametersonthesubpage,highlightthefunction‐parameteryouwishtoedit,andthenpress
the>buttontomovethecursorintothesubpage.
Function Parameter Range of Values Default
Pitch
Pitch -128 to 127 semitones 0
Fine Adjust ± 100 cents 0
Hertz Adjust ± 10.00 Hertz 0
Key Tracking ± 2400 cents/key 0
Velocity Tracking ± 7200 cents 0
(Function) (Function-Parameter) (Depends on Function) (Depends on Function)
(Function) (Function-Parameter) (Depends on Function) (Depends on Function)
(Function) (Function-Parameter) (Depends on Function) (Depends on Function)
(Function) (Function-Parameter) (Depends on Function) (Depends on Function)
Level
Level -96 to 24 decibels -6
Key Tracking ± 2.00 decibels/key 0
Velocity Tracking ± 96 decibels 35
