4. Structure and parameter of electrical system (Table 7)
Table 7 Structure and Parameter of Electrical System
Name Structure and parameter
Wire Single wire, negative pole grounded, direct current 12V
Generator Integral type, AC, built-in voltage regulator, specification 14V/80A
Motor solenoid-operated (with generator), power 1.2kw
Electronic fan Without speed regulation single fan
Start
Battery Maintenance-free plumbic acid battery, capacity 60Ah
Front combination lamp
Headlamp (55/55W, white, 2 lamps),
position lamp (0.8W, LED, white),
steering light (21W, amber, 2 lights, both combination switch)
Side steering light 12V, 0.6W, amber, 2 lights
Front and rear fog lights
Front fog light (55W, white, 2 lights), rear fog light (3W, LED, red,
combination switch), rear position lamp (1W, LED, red)
Rear combination lamp
Brake lamp (1.2W, red, 2 lamps, contact closed switch),
Reversing lamp (21W, white, 2 lamps), steering light (21W, amber,
2 lamps, combination switch), rear position lamp (0.8W, LED, red)
Rear license plate lamp 5W, white, 2 lamps
High-mounted brake lamp LED, LED, red, 1 lamp
Inner combination roof light 5W, white, 2 lights
Illumination and
signal
Door lamp 6.2W, white, 4 lamps
Instrument cluster
Instrument cluster with electronic odometer, including LCD water
thermostat, fuel gauge, vehicle odometer, engine rotation speed
Including battery charge indicator, engine oil pressure indicator, fuel
warning indicator, brake fluid level indicator, engine fault indicator,
handbrake indicator, anti-theft indicator, safe belt indicator,
electronic airbag indicator, instrument illumination light, high beam
indicator, fog light indicator, steering light (emergency lamp)
indicator, ABS indicator, door ajar indicator.
Instrument
system
Indicator
Brake indicator, anti-theft indicator, safe belt indicator, electronic
airbag indicator, instrument illumination light, high beam indicator,
fog light indicator, steering light (emergency lamp) indicator, ABS
indicator, door ajar indicator.
Electric assistant
system
Including CD (or DVD) player, cigar lighter, rear defroster, wiper and
washer, remote door lock, anti-theft system, airbag, window
regulator.
