Lifan 620 - J1-07 Not Used J1-08; J1-10 Not Used J1-11; J1-13 Not Used J1-14; J1-16 Not Used J1-17

Table 1-1 (Continued)
Pin
Number
Definition
Pin
Number
Definition
Pin
Number
Definition
J1-34
Idle speed phase A output
negative
J1-35 Acceleration signal J1-36 Power steering signal
J1-37 Not used J1-38
Rear oxygen sensor signal
high
J1-39 A/C demand (+)
J1-40 Not used J1-41 Not used J1-42 Intake air pressure
J1-43 Coolant temperature J1-44 Not used J1-45 Tachometer
J1-46
A/C compressor clutch
relay control
J1-47 Fuel pump relay control J1-48 Not used
J1-49 Instrument power supply J1-50 High speed fan relay control J1-51 Not used
J1-52 Ignition coil B J1-53
Idle speed phase A output
negative
J1-54
Idle speed phase A
output positive
J1-55 Fuel injector of cylinder 1 J1-56 Fuel injector of cylinder 3 J1-57
J1-58 Not used J1-59 Not used J1-60 Not used
J1-61
Front oxygen sensor
heating control
J1-62
Front oxygen sensor signal
high
J1-63
Canister solenoid
valve control
J1-64
Rear oxygen sensor
heating control
J1-65 Not used J1-66 Not used
J1-67
Low speed fan relay
control
J1-68 Not used J1-69 Knock signal
J1-70 Fuel injector of cylinder 2 J1-71 Fuel injector of cylinder 4 J1-72 Not used
J1-73 System ground wire
