2. Installation process and notes
(1) Install a new driver air bag module, and plug the interface between the clock spring and gas
generator.
Note: Engage the black interface buckle in the gas generator. Then plug the horn wire interface.
(2) Place the whole module in the steering wheel, adjust the position of the air bag module and
ensure the equality of the gap at the four corners. And then screw two hexagon bolts into the
corresponding position using hexagon socket wrench at the torque of 8 N·m.
(3) Check the middle of steering wheel. After installation, gently revolve the steering wheel to left
and right, making sure that no noise or something abnormal exists.
3. Note for maintenance
For the driver air bag module of the LF7162, there is no need for maintenance of any part except
repairing and changing the horn. If trouble occurs, install a new one.
Note: Make sure that new component is installed by the professionals at the designated service
center.
III. Notes for removal, installation and maintenance of front passenger air bag
module (PAB)
1. Removal process and notes
(1) Locate the ignition switch in position LOCK.
(2) Disconnect the negative cable of the battery for more than 3min.
(3) Remove the trim strip of the sundries box door in the sundries box of dash board, unscrew the
bolts connecting front passenger air bag module with tubular beam by the wrench.
Note: When handling the air bag interface, take care not to damage the air bag harness.
(4) When dismantling the sundries box of dash board, gently uplift the dash board, and pick up the
interface in the air generator terminal of front passenger air bag with a mini-type straight
screwdriver.
(5) Remove the front passenger air bag module. Dismantle the nuts fixing the front passenger air
bag module and dash board with a wrench, draw out the ropes tied on the front passenger air bag
from the gap, take out the front passenger air bag module from the top of the dash board. Seal the
old front passenger air bag module removed in a sealing bag, and return it to Chongqing Lifan
Passenger Vehicle Co., Ltd.
Note: Forbid to disassemble the front passenger air bag module.
2. Installation process and notes
(1) Install a new front passenger air bag module. Place the module mount rightly into the
corresponding bolts on the dash board. And tighten the three flange locknuts with the wrench at
the torque of 8 N·m.
(2) Unscrew the bolts on the draw cord ring, then put the draw cord on the dash board into the
draw cord ring of the air bag module, screw the bolts at the torque of 8N·m.
(3) After installing the dash board at the corresponding position in the car, plug the interface of air
bag harness into the corresponding air generator terminal of front passenger air bag module.
(4) Fix the dash board on the car.
(5) At this moment, the installing hole at the bottom of the air bag module shall directly face the
installing hole at the tubular beam. Fix them with the bolt.
(6) Install the sundries box.
