Section IV Front Side Door
I. Decomposition Diagram. See Fig. 7-5:
Fig. 7-5
1. Right front safety belt retractor 2. Safety belt head guard cap
3. Hexangular flange bolt (a) 4. Hexangular flange bolt (b)
5. Hexangular flange bolt (c) 6. Hexangular flange bolt (d)
7. Safety belt altitude controller assembly 8. Left front safety belt retractor
9. Rear seat safety belt retractor assembly 10. Hexangular flange bolt (e)
11. Rear seat double connection lock buckle assembly 12. Rear seat lock buckle and waist belt assembly
II. Front side door glass, as shown in Fig. 7-5:
1. Removal:
(1) Remove the front side door glass frame riser switch assembly.
(2) Remove the front side door guard panel.
(3) Remove the front side door sealing film.
(4) Connect the glass frame riser switch, lower the glass to the reasonable position (reveal the two
installing holes of the glass).
(5) Dismantle the bolts for glass installation.
(6) Dismantle the glass of the front door.
2. Installation: install the glass of the door as per the opposite process, and pay attention to the
following notes:
(1) Check whether the top of the glass and the sliding channel contact evenly or not, and the
up-and-down movement is stable or not during the installation.
(2) Adhere the door sealing film firmly with the adhesive.
III. Glass frame riser:
1. Removal
