Lifan 620 - Radio Assembly of Audio System; Definition of Harness Terminal of Speaker

Radio assembly of audio system: Fig. 4-106
Fig. 4-106
(Definition of harness terminal of speaker) Refer to Fig. 4-107 and Table 4-20.
1
2
P10
P9
12
T
6
T5
R20
R21
1
2
Fig. 4-107
Table 4-20
Testing terminal Wire color Terminal description Test condition Standard value
1-body — Speaker drive input Audio system in process —
2-body — Speaker drive input Audio system in process —
256
