Front and rear shock dampers and front and rear sub-frames mounting holes
coordinate:
Hole name
X (mm) Y (mm) Z (mm)
Sub-frame mounting hole 1
56.9 -455.6 113.0
Sub-frame mounting hole 2
56.9 455.6 113.0
Front shock damper mounting hole 1
-39.7 -568.3 621.4
Front shock damper mounting hole 2
59.3 -625.5 619.2
Front shock damper mounting hole 3
59.2 -511.3 614.4
Front shock damper mounting hole 4
-39.7 568.3 621.4
Front shock damper mounting hole 5
59.3 625.5 619.2
Front shock damper mounting hole 6
59.2 511.3 614.4
Rear axle mounting hole 1
2196.5 -616 0
Rear axle mounting hole 2
2196.5 -512 0
Rear axle mounting hole 3
2196.5 616 0
Rear axle mounting hole 4
2196.5 512 0
Rear shock damper mounting hole 1
2442 -537.1 280.5
Rear shock damper mounting hole 2
2583.5 -536.1 280.4
Rear shock damper mounting hole 3
2576 -491.9 275.9
Rear shock damper mounting hole 4
2442 537.1 280.5
Rear shock damper mounting hole 5
2583.5 536.1 280.4
Rear shock damper mounting hole 6
2576 491.9 275.9
Vehicle body coordinates origin: X0 is in the center of front axle; Y0 is in the bilateral symmetry
center; and Z0 is in the upper surface of middle floor.
