IV. Trouble Symptom Table 4-3
Table 4-3
Symptom Cause Symptom Cause
1
Instrument cluster
does not work
1 Faulty fuse
2 Faulty wiring and connector
3 Faulty instrument cluster
2
Speedometer
fault
1 Faulty speed sensor
2 Faulty wiring and connector
3 Faulty instrument cluster
3
Tachometer fault
1 Faulty engine or ECM
2 Faulty wiring and connector
3 Faulty instrument cluster
4 Fuel gauge
fault
1 Faulty fuel level sensor
2 Faulty wiring and connector
3 Faulty instrument cluster
5
Water thermometer
fault
1 Faulty coolant temperature sensor
2 Faulty wiring and connector
3 Faulty instrument cluster
6 Reverse
radar alarm
buzzer does
not work
properly
1 Faulty instrument cluster
2 Faulty BCM controller
3 Faulty reverse radar probe
4 Faulty reversing switch
5 Faulty key unlocking alarm
switch
6 Faulty wiring and connector
7
Seat belt reminder
buzzer does not
work properly
1 Faulty door lamp switch of four
doors
2 Faulty air bag ECU
3 Faulty wiring and connector
4 Faulty instrument cluster
8 Door ajar
buzzer does
not work
properly
1 Faulty door lamp switch of
four doors
2 Faulty wiring and connector
3 Faulty instrument cluster
V. Electrical check
1. Instrument cluster doesn’t work
(1) Check steps
1) Check the power (60A) fuse of driver’s cabin (located on the distribution box inside the engine
room). If it is in a normal condition, go to step 2), if not, change the fuse of instrument.
2) Check the live (10A) fuse of instrument cluster (located on the fuse box of instrument desk). If it
is in a normal condition, go to step 3), if not, change the fuse of instrument.
3) Check the ignition (5A) fuse of instrument cluster (located on the fuse box of instrument desk). If
it is in a normal condition, go to step 4), if not, change the fuse of instrument.
4) Check the instrument cluster.
Remove the instrument cluster, ignition switch on-position, check the voltage between
connector terminals A18, A19 and A20 of instrument cluster and the body, normally around 10
14V.
Check the resistance between connector terminal A9 and the body, normally less than 1. If it
is in a normal condition, replace the instrument cluster, if not, repair or change the wire and
connector.
(2) Check the circuit as shown in Fig. 4-20.
2. Speedometer fault
(1) Check steps
1) Check the power input end of speed sensor.
Ignition switch ON-position, check the voltage between 1-T2 and the body, normally around 10
14V.
201
