5. Power window circuit (Fig. 4-37)
Fig. 4-37
6. Power window trouble symptom table (Table 4-7)
Table 4-7
Symptom Cause
All power windows do not work
1. Faulty BCM controller
2. Faulty glass frame riser power fuse
3. Faulty wiring
One power window does not work
1. Faulty glass frame riser switch of corresponding door
2. Faulty glass frame riser motor
3. Faulty wiring
Window locking system does not
work
1. Faulty safety switch of left front door glass frame riser
switches
2. Faulty wiring
