Section III Component Maintenance
I. Performance parameter of LF7162 electrical air conditioning system
Table 6-1
Compressor Model WXH-086
Type Parallel flow
Specification L×W×D mm 590×370×16mm
Condenser
assembly
Heat transfer capacity ≥4.5m/s frontal velocity
Type Cascading style
Specification
D×H×W mm
38×250×258
Evaporator
core
Refrigerating
capacity
Intake air flow rate (m³/h) 450, refrigerating capacity
≥4.1Kw
Cascading style
Specification
D×H×W mm
27×220×180
Radiator
core
Heating capacity
For 6L/h flow rate, 350 m³/h air flow rate, heating
capacity ≥4.24.1Kw
Air flow regulation 4
th
gear
Refrigerating face blowing ≥450m³/h
HVAC
assembly
Maximum air flow
Heating foot blowing ≥300 m³/h
Type R134a
Refrigerant
Injection quantity 500g±50g
Type PAG56
Lubricant
Injection quantity 120ml
Maximum refrigerating capacity Compressor 1800 revolutions, ≥4.0K Air
conditioning
system
Temperature regulating range
18℃～32℃
