Lifan 620 - Hole Usage Description

S/N
Measuring
point
Dimension
parameter
(mm)
Remark S/N
Measuring
point
Dimension
parameter
(mm)
Remark
1 A-a 690 17 I-K 1223.6
2 A-B 835.2 18 I-L 1146.4
3 A-C 685.2 19 L-l 1490.6
4 B-b 1365 20 M-m 1126.5
5 C-c 1136.6 21 M-N 834.7
6 C-b 1256.4 22 M-O 1024.9
7 C-d 1147.4 23 N-O 374.8
8 C-E 952.8 24 P-p 1066.6
9 C-F 706 25 Q-q 1028
10 D-d 911.5 26 R-r 1524.9
11 D-E 888 27 S-s 1398
12 D-F 507.9 28 T-t 1097
13 E-F 848.8 29 β-β 1506.7
14 G-H 1437.9 30 δ-δ 1550.2
15 I-i 1130.4 31 P-β 1608.7
16 I-J 1255.2 32 G-g 1056.4
Hole usage description
S/N Remark S/N Remark
A, a
Engine radiator assembly mounting
hole
Q, q Rear panel weld positioning hole
B, b Fender mounting hole R, r
Rear bumper connecting piece mounting
hole
C, c
Front shock damper assembly
mounting hole
S, s Tail lamp mounting hole
D, d Sub-frame assembly mounting hole T, t Tail lamp mounting hole
E, e Engine girder mounting hole U, u Engine radiator assembly mounting hole
F
Four-way proportional valve
mounting hole
V, v Front floor weld positioning hole
J Door sill technical hole W, w Front floor weld positioning hole
K Front door limiter mounting hole X, x Rubber cover stem mounting hole
L Fender mounting hole Y, y
Rear shock damper assembly mounting
hole
N Rear door limiter mounting hole Z, z Rear towing eye hook
O Door sill technical hole
