Section V Illumination System
I. Overview
The illumination system is to offer lighting for night driving, consists of outer lights of headlight,
backup light, license plate lamp, fog light etc, and inner ones of dashboard light, inner light,
luggage boot lamp, door lamp, various backlights etc. Each light is installed at required position,
equipped with control switch, wire, fuse protector and so forth, to make up the illumination system,
which also enjoys signal indication, comes out with light signals to warn the driver of another car
and the foot passenger, to ensure safe driving, including signals for steering, brake, danger
warning, outline marker etc. The components as shown in Table 4-13
Note: Do not use bulbs without specifications indicated in the table below, or the car lamps will be
damaged. Do not touch the halogen lamp or get it contacted by oily surface, or the bulb’s life will
be shortened.
Table 4-13
Name Model Technical parameter
Low beam of front combination lamp H1 12V55W
High beam of front combination lamp H3 12V55W
Position lamp of front combination lamp LED 12V 0.8W
Steering light of front combination lamp PY21W 12V21W
Side turn signal light WY5W 12V5W
Front fog light H3 12V55W
Position lamp of rear combination lamp LED 12V1W
Brake lamp of rear combination lamp LED 12V1.2W
Backup light of rear combination lamp P21W 12V21W
Steering light of rear combination lamp PY21W 12V21W
Rear fog light of rear combination lamp LED 12V3W
License plate lamp W5W 12V5W
High-mounted brake lamp LED 12V0.5W
Rear roof light (Q)-12V5W 12V5W
Luggage boot lamp W5W 12V5W
Door lamp LED 12V0.24W
