Table 1-2 continued
J1-35 Acceleration signal 48.8K ±0.5K
J1-36 PSTE Power assisted steering 7.1M ±0.2M
S/N Mark Name Resistance value Tolerance
J1-37
J1-38 VLS-DN-A Rear oxygen signal 42.6K ±0.3K
J1-39 ACIN A/C demand 9.9K ±0.2K
J1-40
J1-41 P/N Park/Neutral switch 13.3M ±0.5M
J1-42 MAP Manifold 51.1K ±0.2K
J1-43 TCO Coolant sensor 3.4K ±0.1K
J1-44
J1-45 ESS Tachometer ∞
J1-46 ACCIN A/C compressor relay clutch
switch
∞
J1-47 RLY-EFP Fuel pump relay control ∞
J1-48
J1-49 FUEL-IN Fuel position sensor 3.3K ±0.1K
J1-50 RLY-FAN-H High speed fan relay ∞
J1-51
J1-52 IGC2 Ignition coil of cylinder 2,3 1.2M ±0.1M
J1-53 STPAL Stepper motor A- 20.4K ±0.5K
J1-54 STPAH Stepper motor A+ 20.5K ±0.5K
J1-55 IV0 Injector 1 1.3M ±0.2M
J1-56 IV2 Injector 3 1.3M ±0.2M
J1-57
J1-58 RLY-MAIN Main relay control ∞
J1-59
J1-60
J1-61 VLS-UP Front oxygen heating control 1.3M ±0.1M
J1-62 VLS-UP Front oxygen signal 42.3K ±0.1K
J1-63 CPPWM Canister solenoid valve 1.4M ±0.1K
J1-64 VLS-DN Rear oxygen heating control 1.3M ±0.1M
J1-65
J1-66
J1-67 FANL Low speed fan control ∞
J1-68
J1-69 KNKS Shock sensor signal 99.3K ±0.5K
J1-70 IV1 Injector 2 1.3M ±0.2M
J1-71 IV3 Injector 4 1.3M ±0.2M
J1-72
J1-73 GND System ground wire 0.0Ω
To Next Page
