3. Remove mudguard of left front wheel.
(a) Remove 2 screws.
(b) Remove mudguard of left front wheel.
Notes:
It is not necessary to completely remove the mudguard of left front wheel; the bumper can be
removed in Step 4 if it is partly removed.
4. Remove mudguard of right front wheel. Notes: the same with Step 2.
5. Remove the other 2 screws connecting front bumper and engine mudguard.
6. Remove front bumper.
① Put protecting tape on the fender.
② Remove the 2 self-tapping screws connecting the left and right corners of front bumper and the
fender.
③ Disconnect the 4 jack catches at left and right and the bumper with a screwdriver.
Notes:
Wrap the screwdriver tip with adhesive tape before use.
Disconnect the 2 fog light interfaces (optional).
7. Remove left fog light assembly
Remove screw and fog light.
8. Remove right fog light assembly.
Remove screw and fog light.
9. System with clearance sonar: Remove sonar retainer and sonar with screwdriver.
Notes: Wrap the screwdriver tip with adhesive tape before use.
10. Remove left connection bracket of front bumper with needle nose pliers.
11. Remove right connection bracket of front bumper.
Notes: the same with Step 8
12. Remove front bumper framework
Jack catch
Front bumper
Front grille
Left connection bracket of front bumper
Notes:
Wrap the screwdriver tip with adhesive tape before use.
Remove 4 nuts, 4 bolts and front bumper framework.
13. Install left connection bracket of front bumper.
14. Install right connection bracket of front bumper.
15. Install front bumper framework.
Install front bumper framework with 4 nuts and 4 bolts.
16. Install left connection bracket of front bumper.
17. Install right connection bracket of front bumper.
18. Install front bumper framework.
19. Install front grille with 2 bolts.
