③ Remove the 2 bolts in the left side of rear bumper.
④ Remove the 2 bolts in the right side of rear bumper.
⑤ Remove the 2 BL1409 snap buttons in the bottom of rear bumper.
⑥ Put protecting tape under the side wall plate.
⑦ Disconnect the rear bumper and left and right connection brackets. Notes: Disconnect the 4
jack catches in the left and right with screwdriver.
⑧ After disconnecting rear bumper and left and right connecting pieces of rear wall, remove rear
bumper. Notes: Pull backwards lightly the rear bumper with holding its two sides by hands and
shake lightly from side to side to disconnect rear bumper from the jack catches of left and right
connecting pieces of rear wall of rear bumper.
⑨ System with radar probe: Disconnect interfaces of probe wire.
10. System with radar probe: Remove the probe.
11. Remove left connection bracket of rear bumper.
12. Remove the right connection bracket of rear bumper.
13. Remove framework of rear bumper: Rear bumper framework can be removed after the
removal of 6 nuts.
14. Remove left mounting bracket of rear bumper framework: Remove the 3 bolts and left
mounting bracket of rear bumper framework.
15. Remove right mounting bracket of rear bumper framework: Remove the 3 bolts and right
mounting bracket of rear bumper framework.
16. Install left mounting bracket of rear bumper framework: Install with 3 bolts; fixing torque:
11.5N·m.
17. Install right mounting bracket of rear bumper framework: Install with 3 bolts; fixing torque:
11.5N·m.
18. Install rear bumper with 4 buckles and 4 screws and 4 blots in the 2 sides. To install, reverse
the removal steps.
