10.7 Summary of Faults and Warnings
This section lists all printer Faults and Warnings messages. the printer displays these
messages in a notification screen if a problem occurs. If the printer displays an events
message that is not described in this section, you should inform you supervisor, or contact
your local Linx Distributor. See Table 9-18 below for a list of all printer Faults and Warnings.
Table 10-18. Faults and Warnings summary table
1. System Faults 2. Print Failures 3. System Warnings
1.03 Internal Software Failure
(ASSERT)
2.00 Printhead Over Temperature 3.00 Shutdown Incomplete
1.40 EHT Board Missing 2.01 EHT Trip 3.05 Over Speed (Print Trigger)
1.42 I2C Bus Failure 2.02 Phase Failure 3.06 Over Speed (Synchronous
Data)
1.43 Watchdog Trip 2.03 Time Of Flight Failure 3.07 Over Speed (Asynchronous
Data)
2.06 Solvent Tank Empty 3.08 Over Speed (Line Speed)
2.07 Internal Spillage 3.09 Over Speed (Compensation)
2.08 Printer Over Temperature 3.10 Under Speed (Line Speed)
2.09 Misaligned Ink Jet 3.12 Printhead Cover Off
2.11 Pressure Limit Reached 3.13 Cover Override Active
2.12 Viscosity Out Of Range 3.15 Safety Override Active
2.20 Ink System Empty 3.16 Gutter Override Active
2.21 Service Module Removed 3.17 Gate Array Test Mode Active
2.22 Unable to Fill Service Module 3.18 Low Pressure
2.23 Charge Amplifier Trip 3.19 Valid UNIC Chip Not Found
2.24 Memory Low 3.29 Over Speed (No Remote
Data)
2.25 Memory Storage Low 3.30 Remote Error
2.26 Modulation Amplifier Trip 3.40 Service Module Requires
Replacement
2.27 Service Module Requires
Replacement
3.41 Service Module Removed
2.28 Valid UNIC Chip Not Found 3.42 Service Module Requires
Commissioning
2.29 Pump Drive Failure 3.43 Memory Low
2.30 Pressure Reading at
Maximum
3.44 Memory Storage Low
2.31 Pressure Reading Suspect 3.45 Service Module Replacement
Due Within One Month
