Gocator Line Profile Sensors: User Manual

Gocator Web Interface • 203

Measurements, Features, and Settings

Measurement Illustration

Area

Measures the cross-sectional area within a region that is

above or below a fitted baseline.

Centroid X

Determines the X position of the centroid of the area.

Centroid Z

Determines the Z position of the centroid of the area.

Measurements

Type Description

Center Point

The center point of the area.

Features
